  • Thermal Overload Relays

    Use a thermal overload relay to thermally protect your motor in case of phase failure or overload. In combination with auxiliary contacts this is the safest protection for your motor.

Thermal Overload Relays

Thermal overload relays are installed in the main circuit when electromechanical protection is adequate. This protects the motor in case of phase failure or overload. The thermal overload relay does not directly shut down the load. Instead, it triggers one or several auxiliary contacts which then disconnect the motor. Most thermal overload relays can be mounted directly to the contactor. Thermal overload relays have three pins. They contain a thermal release - hence the name - usually a bimetal element. Direct or indirect heating caused by overload bends the bimetal release and the relay trips.



Contactors
Contactors

Precise and Reliable Motor Control with Schrack Technik Contactors.

Motor Protection Switches
Motor Protection Switches

Protect your motor with the BE Series motor protection switches from Schrack Technik.

Combination Contactors
Combination Contactors

Pre-assembled combination contactors - ready for use with Schrack Technik.

Modular Contactors
Modular Contactors

Automate Your Processes and Activities with Modular Contactors from Schrack Technik.

Auxiliary Contactors
Auxiliary Contactors

Schrack Technik auxiliary contactors complement your main contactors.

Vacuum Contactors
Vacuum Contactors

Schrack Technik vacuum contactors are an alternative to air contactors.

Thermal Overload Relays

Since a thermal overload relay will not trip in case of a short circuit, additional fuses are necessary for short circuit protection.  The thermal overload relays from Schrack Technik have an additional phase failure protection, which monitors voltage in the three-phase AC live wires. The thermal overload relays from Schrack Technik can be reset manually and automatically. They have a testing function and a STOP button.

Protect your motor in case of phase failure or overload with a thermal overload relay from Schrack Technik.
